SQLab Saddle 6OX Ergowave active 2.1
The 6OX ERGOWAVE® is not only our bestseller, but also the most popular saddle in the trade press. In reader surveys, it makes SQlab repeatedly the most popular E-MTB saddle brand in Germany.
- In Stock Items Will ship in 2-3 business days
- Special Order Items will be ordered for you and shipped when available
- More information? Contact us about this product
- Add to comparison list
Perfect Fit
The correct saddle width is a key for maximum performance.
Available widths in cm: 13, 14, 15, 16
More free space - less pressure
The proven, outstanding SQlab staged saddle shape with the saddle nose that dips below level also provides more freedom for the 6OX and less pressure, equally so for men and for women.
Pressure measurement SQlab 6OX
The pressure mapping diagram shows an optimal pressure distribution from a medical point of view on the sit bones and pubic bones. Almost no pressure is exerted on the perineal area.
Perfect hold
The SQlab saddle shape with the raised seat surface is already perfectly suited for riding uphill and also provides more power to the pedals on straights. Additionally, a special non-slip logo design ensures even more grip towards the back.
Gripdesign
The grip material on the raised stage provides additional hold towards the back.
Relief of the intervertebral discs
Elastomere - hard, medium, softSaddle Setup
- ARTICLE NUMBER(S): 2447 / 2448 / 2449 / 2450
- AREA OF USE/BICYCLE TYPE: MTB GRAVITY & E-PERFORMANCE
- WEIGHT(S) IN G: APPROX. 262 / 267 / 272 / 277
- LENGTH(S) IN MM: APPROX. 280
- ACTIVE TECHNOLOGY: YES -SPORT
- MOUNTING HEIGHT IN MM: APPROX. 49
- SIZE(S) IN CM (EFFECTIVE SADDLE WIDTH): 13 / 14 / 15 / 16
- MATERIAL RAILS: S-TUBE (LIGHT METAL ALLOY - HOLLOW)
- MATERIAL BASE: GLASS FIBRE REINFORCED POLYAMIDE COMPOUND (PA12 + GF)
- MATERIAL PADDING: SUPERLIGHT FOAM
- MATERIAL COVER: MICROFIBRE
- HARDNESS IN SQ-SHORE: 55
- RELIEF OF PERINEAL AREA IN %: 72
- MAXIMUM LOAD IN KG: 110
- MAXIMUM TORQUE IN NM: 18
- E-BIKE READY: YES
- DIN/ASTM CATEGORIES: 5
- GENDER: UNISEX
The 6OX ERGOWAVE® is not only our bestseller, but also the most popular saddle in the trade press. In reader surveys, it makes SQlab repeatedly the most popular E-MTB saddle brand in Germany.
The ERGOWAVE® shape and the active system improve the saddle in many details and make it unbeatable on the e-bike in terms of relief, comfort, technology. In particular, the important support to the rear has been increased.
+ Comfort
+ Relief
+ Support
+ Lighter weight
+ Perfect for the E-MTB, but also for the All-Mountain and Enduro Bike
The wave shaped 6OX profile which contours from the rear to the front offers a perfect form-fit shape for most sit bones. The raised back section provides more rearward support and ensures efficient power transmission. The grip material on the raised back provides additional support to the rear. In addition, the saddle cover is robust, especially at the edges.
The level and lowered saddle nose applies less pressure to the sensitive areas of men and women alike. For an even better pressure relief, especially on long technical climbs, the saddle nose of the 6OX became a little bit wider, but just as flat and with largest possible surface area. The padding was designed for the specific needs on the E-MTB with perfect dampening properties for rough off-road terrain.
The active system has not only become lighter, but also much smoother. This increases comfort for the sit bones as well as relieving pressure on the intervertebral discs. In particular, the mobilization of the intervertebral discs is now clearly noticeable. The active-movement is even more adjustable in the
new models, as the elastomers have become smaller and lighter.
| Brand | SQlab |
| Article code | 11737 |
| SKU | 2447 |
| EAN | 4062695001546 |
